SOFT SLING WEBBINGS

POLYESTER SLING WEBBING FOR LIFTING AND RIGGING

文章附图

Soft Sling Webbings

We have wide range of webbings from tested high tenacity polyester yarn and complete range of polyester webbings for web slings and tie downs from 25mm to 300mm width. The webbings are manufactured as per American Standards and European Standards and are available in rolls of 100m or any cut length as per customer's requirements. Both weaving, Dyeing, customized printing and stretching facilities for webbings are very professional.


European style flat


No.Spec.safety factor(7:1)ColorWidth/mmBreaking strength (ton)
11TViolet304.5
22TGreen608.9
33TYellow9013.5
44TGrey12018.0
55TRed15022.0
66TBrown18026.9
88TBlue24036.0
1010TOrange30043.5



European Style Round Sleeves

No.Spec.safety factor(7:1)ColorWidth/mm
1IT round sleevesViolet45
22T round sleevesGreen49
33T round sleevesYellow65

44T round sleevesGrey74
55T round sleevesRed80
66T round sleevesBrown89
1010T round sleevesOrange107
31Singe eye protectionGrey108



American Style Flat Sling Webbing

No.Width (inch)Lbs/inchColor
119800Yellow
229800Yellow
339800Yellow
449800Yellow
559800Yellow
669800Yellow
789800Yellow
8109800Yellow
9129800Yello



European Style Tie Down Webbings

No.Breaking strength (tons)
ColorWidth/mm
15any color50
26any color50
47.5any color50



American style tie down webbings

No.
breaking strength(1bs)colorwidth/inchmark line
16000yellow2one line in the edge
210000yellow2one line in the middle
320000yellow4one line inthe middle
412000yellow2one line in the middle
518000yellow3one line in the middle
624000yellow4one line in the middle
